概览
RCLAMP0801H is a low capacitance ESD protection device specifically designed to protect highspeed Ethernet lines. It offers desirable characteristics for board-level protection, including fast response time, low operating and clamping voltage, and no device degradation. This device feature a large cross-sectional area for conducting high surge capability of 30A-36A (tp= 8/20 μs).
功能
- High ESD withstand Voltage
- IEC 61000-4-2 (ESD): 30kV (Contact), 30kV (Air)
- IEC 61000-4-5 (Lightning): 30A-36A (tp = 8/20μs)
- Protects one high-speed data line
- Working voltage 8V
- Low capacitance: 3.3pF typical
- 固态硅雪崩技术
| 文档 | Release Date | Type |  |
|---|---|---|---|
| RCLAMP0801H Datasheet | 2024-12-14 | | |
应用
- Telecom
- 工业
- 10/100/1000 Ethernet
- DOCSIS modems
- USB 2.0
