SC5010
Product inactive. Information on this page is for reference only.
The SC5010 is an 8-channel high-precision, high-efficiency step-up (Boost) LED driver for backlight applications. It features wide input voltage range (4.5V to 27V) , fl exible output configuration, wide analog and PWM dimming range, phase shifting and fading. It also features video signal synchronization (VSYNC), I2C interface, and numerous protection features. An optional disconnect p-MOSFET provides true load disconnection and inrush current limiting.
功能
- VIN Range — 4.5V to 27V, VOUT Range — Up to 50V
- Step-up (Boost) Controller
- Excellent Transient Response
- Programmable Switching Frequency
- Linear Current Sinks
- 8 Strings, up to 30mA/String
- Current Matching ±1%
- Current Accuracy ±1.5%
- PWM Dimming
- String-by-String Phase Shifting
- Input Dimming Frequency 100Hz-30kHz
- User Selectable 9 or 10 Bits Dimming Resolution
- Optional Synchronization to VSYNC/HSYNC Signal
- 5-bit Analog Dimming
- Optional External p-MOSFET Disconnect Switch
- True Load Disconnect and Inrush Current Limiting
- I2C Interface
- Fault Status — Open/Short LED, UVLO, OTP
- Device Control — SYNC Freq, PLL Setting
- Protection Features
- Open/Shorted LED(s) and adjustable OVP
- Over-Temperature and UVLO Shutdown Protection
- 4 X 4(mm) 28-pin QFN Package
- Notebook PCs
- UMPC
- LCD Monitors
- Tablet PCs
应用
封装
- QFN 28-pin package.
订购代码
- SC5010ULTRT - Lead-free, WEEE, RoHS compliant, and halogen-free. 3,000 pcs, tape and reel only.
Pb(Lead)-Free/RoHS-Green Info
Base Part Number (1)
SC5010
产品描述
HIGH EFFICEINCY 8-CHANNEL LED DRIVER WITH I2C INTERFACE AND PHASE-SHIFTED PWM DIMMING
引脚数
28
封装类型
MLPQ-UT
Pb-Free (2)
是
Reflow Temp °C (3)
260
引脚或焊球镀层
MATTE Sn
MSL 等级
1
JIG 101 A & B (12)
是
WEEE 2012/19/EU (19)
是
China RoHS 2 GB/T 26572-2011
是下载报告
RoHS Compliant by Exception (8)
否
Whisker Testing (10)
热循环锡须测试
（-40°C 至 +85°C / 4000 循环）
（-40°C 至 +85°C / 4000 循环）
是
环境温度存储，锡须测试
（50°C，4000 小时）
（50°C，4000 小时）
是
60°C/90% 相对湿度 4000 小时，锡须测试
是
声明和报告
